Simplex 4010 User Manual

8-21
ON/CODE and OFF
When using the input condition qualifier ON/CODE (On Coding), a statement is
true when the point indicated in Field 4 is On or Coding. Field 4 choices for the
ON/CODE qualifier are:
• CPU Card Points
• System Card Points
• Power Supply Points
• Digital Pseudo Points
• Analog Pseudo Points
Note: The statement holds true until the point indicated in Field 4 is
OFF.
[ ] [ ] [ON/CODE] [3-01]
Figure 8-26
Example: The condition of 3-01 is ON/CODE. The input of the equation
remains true until the point indicated in Field 4 is OFF.
When using the input condition qualifier OFF, a statement is true when the point
indicated in Field 4 is OFF. Field 4 choices for the OFF qualifier are:
• CPU Card Points
• System Card Points
• Power Supply Points
• Digital Pseudo Points
• Analog Pseudo Points
Note: The statement holds true until the point indicated in Field 4 is ON
or Coding.
[ ] [ ] [OFF] [3-01]
Figure 8-27
Example: The condition of 3-01 is OFF. The input of the equation remains
true until the point indicated in Field 4 is ON or Coding.
Continued on next page
Custom Control Programming, Continued
Fields 3 & 4 (Continued)
Field 1
Field 1
Field 2
Field 2
Field 3
Field 3
Field 4
Field 4
FIRST
STATEMENT
FIRST
STATEMENT
Pro
g
rammin
g
Technical Manuals Online! - http://www.tech-man.com

Simplex 4010 Specifications

General

Display	LCD
Power Supply	120/240 VAC, 50/60 Hz
Manufacturer	Simplex
Model	4010
Battery Backup	24 VDC
NAC Outputs	4
Max Detectors	250
Max Modules	250
Operating Temperature	0°C to 49°C (32°F to 120°F)
Humidity Range	Up to 93% RH, non-condensing
