Protocol Parameters (ATS)
The table below contains the parameters recommended by LivaNova for the ATS protocols, according
to the bowl size used.
Note: Every time a new case is started, factory procedure parameters are reinitialized to their
default values, even if the unit is not shut down and restarted.
Protocol Parameters Range Step Unit Factory values
X/55 X/125 X/175 X/225
Popt Starting Fill Flow
i
25 - 1000 25 ml/min 300 450 550 400
Final Fill Flow
i
25 - 1000 25 ml/min 300 300 300 250
Wash Flow
ii
25 - 1000 25 ml/min 50->100 250 450 500
Wash Volume
ii
0 - 5000 100 ml 200 800 1000 1000
Empty Flow
ii
25 - 1000 25 ml/min 150 300 400 400
Concentrate flow 25 - 1000 25 ml/min 200 350 450 300
Return flow 25 - 1000 25 ml/min 150 250 250 250
Pstd Fill Flow 25 - 1000 25 ml/min 300 300 350 350
Wash Flow 25 - 1000 25 ml/min 100 250 350 450
Wash Volume 0 - 5000 100 ml 300 900 1000 600
Empty Flow 25 - 1000 25 ml/min 150 250 250 450
Concentrate flow 25 - 1000 25 ml/min 200 350 450 300
Return flow 25 - 1000 25 ml/min 150 250 250 250
Pfat Starting Fill Flow
i
25 - 1000 25 ml/min 550 450 450 550
Final Fill Flow
i
25 - 1000 25 ml/min - - - 250
Wash Flow 25 - 1000 25 ml/min 50->100 250 450 500
Wash Volume 0 - 5000 100 ml 200 800 1000 1000
Fat removal
Wash Flow
i
25 - 1000 25 ml/min 750 750 1000 1000
Fat removal
Wash Volume
i
0 - 5000 100 ml 500 700 700 1000
Fat removal
Empty Flow
i
25 - 1000 25 ml/min 150 300 400 400
Fat removal
Empty Volume
i
0 - 5000 100 ml 50 50 60 60
Fat removal
Conc Flow
i
25 - 1000 25 ml/min 200 350 450 300
Empty Flow 25 - 1000 25 ml/min 150 300 400 400
Concentrate flow 25 - 1000 25 ml/min 200 350 450 300
Return flow 25 - 1000 25 ml/min 150 250 250 250
Emergency
(No
Options)
Fill Flow Rate 25 - 1000 25 ml/min 350 500 450 400
Wash Flow Rate 25 - 1000 25 ml/min 400 800 800 800
Wash Volume 25 - 1000 25 ml 300 800 900 1000
Empty Flow Rate 25 - 1000 25 ml/min 200 500 450 500
Emergency
(No
Wash)
Fill Flow Rate 25 - 1000 25 ml/min 350 500 450 400
Empty Flow Rate 25 - 1000 25 ml/min 200 500 450 500
Emergency
(Rapid
Transfer)
Fill Flow Rate 25 - 1000 25 ml/min 600 600 800 800
Fill Centrifuge Speed 25 - 1000 25 ml/min 0 0 0 0
Empty Flow Rate 25 - 1000 25 ml/min 400 400 600 600
Post-op Starting Fill Flow
i
25 - 1000 25 ml/min 300 450 550 400
Final Fill Flow
i
25 - 1000 25 ml/min 300 300 300 250
Wash Flow
ii
25 - 1000 25 ml/min 50->100 250 450 500
Table 5-2 ATS Protocol Parameter Summary
