sorin XTRA - Collection Set

System Description
X
TRA Operator’s Manual 20077/021 US 3-17
Collection Set
The XTRA Collection set allows the recovery and temporary storage of the blood shed by the surgical
wound. It is composed of:
• Blood Collection Reservoir (TOP or BOTTOM)
• Aspiration Line
• Vacuum Line
• Cardio Kit (only for CARDIO Configurations)
Six configurations of the X
TRA Collection Set are available:
•X
TRA Collection Set CARDIO with TOP reservoir
•X
TRA Collection Set not CARDIO with TOP reservoir
•X
TRA Collection Set CARDIO with BOTTOM reservoir
•X
TRA Collection Set not CARDIO with BOTTOM reservoir (120 μm)
•X
TRA Collection Set not CARDIO with BOTTOM reservoir
•X
TRA Collection Set CARDIO with BOTTOM reservoir (120 μm)
Figure 3-24 XTRA Collection Kit (CARDIO TOP)
12
34
1 Aspiration line 3 Vacuum line
2Reservoir 4Cardio Kit
