Technical Data
X
TRA Operator’s Manual 20077/021 US 16-1
Chapter 16: Technical Data
Technical Features of the Equipment
Unit Dimensions Height = 660 mm (1055 mm*) - pole lowered
Height = 1585 mm (1980 mm*) - pole completely lifted
Height = 835 mm (1230 mm*) - display lifted
Width = 375 mm - including the eccentric rings
Width = 800 mm - with poles completely open
Depth = 500 mm - 680 mm including the front and rear handles
* = with cart.
Cart Dimensions Height = 500 mm
Width = 480 mm
Depth = 595 mm
Unit weight 37 kg
Cart weight 22.5 kg
Display Type: graphic color LCD TFT 8.4"
Dimensions: 172 mm x 130 mm (screen)
Keyboard 1 STOP key
Touch screen keys
Mains voltage (Power
supply)
230 V~ or 100-120 V~
Frequency 50 - 60 Hz
Power absorption Maximum: 320VA (550VA w/ vacuum on Intra mode)
Functioning: 160VA (390VA w/ vacuum on Intra mode)
Fuses 2xT6.3AH (230V~) and 2xT6.3AH (100-120V~)
Power cord Section = 3x1 mm
2
(3x18AWG)
Length = 4 m
Cable / connection
peripherals
X
TRA memory stick
Socket on cords Type C13 (EN 60320/C13)
Plug on cords Type VII (CEE (7) VII)
Type NEMA 5-15
Type BS89/10 (BS 1363/A)
Type I/3 (CEI 23-16)
Unit electrical safety Class I, Type B (EN 60601-1)
Drip proofing IPX1
Table 16-1
