Processing
5-42
20077/021 US XTRA Operator’s Manual
Fat Removal - Wash
Figure 5-40 Fat Removal – Wash processing screen
1. Real Wash Vol. line
The Real Wash Vol. line indicates the total wash volume which has been used during the current cycle,
considering the regular wash volume and that of the running Fat Removal – Wash subphase.
2. Fat Removal – Wash status line
The Fat Removal - Wash status line consists of three elements, from left to right: the grey
wash icon indicating the current phase, a large text field which displays the current volume of
saline solution which has been pumped into the bowl, and a smaller text box which displays
the total volume of saline solution to pump during the current subphase.
Fat Removal - Empty
Figure 5-41 Fat Removal - Empty processing screen
1Real Wash Vol. line
2 Fat Removal - Wash status line
2
1
1 Fat Removal - Empty status line
1
