sorin XTRA - Figure; Top: Y-Type Blood Administration Set with Integral Filter Bottom: Filter with Y-Type Blood Administration Set

Special Cycles
X
TRA Operator’s Manual 20077/021 US 6-9
.
Figure 6-6 Top: “Y”-Type Blood Administration Set with Integral Filter Bottom: Filter with
“Y”-Type Blood Administration Set
1
2
3
4
5
6
7
9
10
1 Primary RBC Bag 6 Secondary Clamp
2 Primary Clamp 7 “Y” Type Blood Administration Set
3 Microaggregate Transfusion Filter 8 “Y” Type Blood Administration Set
without Microaggregate Filter
Installed
4 Blue Tubing from the X
TRA Tube
Set
9Drip Chamber
5 Secondary RBC Bag 10 Distal Clamp
1
3
2
4
5
6
8
9
10
