Processing
5-14
20077/021 US XTRA Operator’s Manual
Fat Removal Button. This button is available only when operating with Pfat protocol.
Touching the Fat Removal button changes to the Fat Removal phase (refer to “Fat Removal
Screens” on page 5-41).
Table 5-1 lists which buttons are made available (in addition to the buttons already present) when
processing is paused from each screen and condition from which the Pause button is available. The
pump is always stopped when the Pause button is touched.
Ending the Current Case
Touch the “End Case” button from the Ready Screen after processing a cycle (refer to
“Running a Case With the X
TRA System” on page 5-5) to end the current case and display the
End of Case Screen (see Figure 5-22).
Condition When Paused Buttons Which Become Available
Intraoperative Fill phase (Automatic, 1 Touch) Return, Conc, Wash, Empty
Intraoperative Fill phase (Manual) Return, Conc
Intraoperative Wash phase (Automatic, 1 Touch) Fill, Empty and Fat Rem (if operating with Pfat
protocol)
Intraoperative Wash phase (Manual) -
Intraoperative Empty phase (Automatic, 1 Touch) Fill, Wash
Intraoperative Empty phase (Manual) -
Preoperative Fill phase (Automatic) Conc, Empty
Preoperative Fill phase (Manual) Conc
Preoperative Spill phase (Automatic) Conc, Empty
Preoperative Spill phase (Manual) Conc
Preoperative Empty phase (Automatic) -
Preoperative Empty phase (Manual) -
Postoperative Fill phase (Automatic, 1 Touch) Like IBS excluding Return: Conc, Wash, Empty
Postoperative Wash phase (Automatic, 1 Touch) Like IBS: Fill, Empty
Postoperative Empty phase (Automatic, 1 Touch) Like IBS: Fill, Wash
Postoperative Empty phase -
Intraoperative, Postoperative (Automatic,
1 Touch): Concentrate from Fill
Fill, Wash, Empty
Intraoperative and Preoperative (Manual):
Concentrate from Fill
-
Preoperative: Concentrate from Spill (Automatic) Spill
Preoperative: Concentrate from Spill (Manual) -
Intraoperative (Automatic, 1 Touch): Return Fill
Intraoperative (Manual): Return -
Intraoperative, Postoperative and Preoperative:
I.V. prime
-
Table 5-1 Buttons Which Become Available While Paused Per Processing Condition
CAUTION
The use of phase buttons and, in general, modifications that alter the normal
execution of protocols can create reductions of normal machine performance.
It is the responsibility of the user to evaluate if and when these procedures
can be performed.
