XTRA Operator’s Manual 20077/021 US B-1

Appendix B: Approvals and Test Certificate

The XTRA and XVAC equipment have been tested and comply with the following:

EMC Standards

(See

Appendix A: Safety Standards EN 60601-1-2

)

EMC Emission

• IEC 60601-1-2 : 2007 and : 2014

EMC Immunity

• IEC 60601-1-2 : 2007 and : 2014

Electrical and Mechanical Safety Standards

• IEC 60601-1 Edition 3.1

Certification

•C-US NRTL Certification

• CB Certification

The LivaNova quality assurance system complies with the following standards:

• UNI - EN - ISO - 13485
