Configuring XTRA
XTRA Operator’s Manual 20077/021 US 8-5
The quality warnings depend on the WLC indicator being enabled. Disabling the WLC indicator
will also disable the “Reached” and “Not reached” quality warning settings.
Wash Quality Warnings
The following two settings relate to the wash quality warnings as described in
Chapter 12: Quality
Management Option
.
Reached. With this feature enabled, if a minimum wash quality is reached before the Wash
phase has completed, the system will issue a warning and allow the operator to switch to the
Empty phase.
Not reached. With this feature enabled, if a minimum wash quality has not
been reached by the
time the Wash phase has completed, the system will issue a warning and continue in the Wash
phase.
Operating Modes
1 Touch. This setting must be enabled to process a cycle in the 1 Touch operating mode as
described in “1 Touch” on page 5-31.
Manual. This setting must be enabled to process a cycle in the Manual operating mode as
described in “Manual” on page 5-32.
Manual RBC option. This setting must be enabled to give the operator the option of disabling
the RBC detector during Manual mode operation. When enabled, the “RBC detector” option will
be displayed in the Protocol/Mode tab of the Menu Screen.
Note: Automatic mode is available in every configuration and cannot be disabled.
Automated Functions
The following two settings relate to automations as described in
Chapter 7: Automated Functions
.
Last Bowl. This setting must be enabled to use the Last Bowl automation as described in “Last
Bowl” on page 7-4.
Better Empty. This setting must be enabled to use the Better Empty automation as described in
“Better Empty” on page 7-7.
Special Cycles
The following two settings relate to special cycles as described in
Chapter 6: Special Cycles
.
Purge. This setting must be enabled to use the special Purge cycle as described in “Removing Air
From the RBC Bag: The Purge Cycle” on page 6-6.
Prime IV. This setting must be enabled to use the special Prime IV cycle as described in “Priming
the Reinfusion Line: Prime IV” on page 6-4.
Data Download Options
The following three settings relate to the data download options as described in
Chapter 11: Data
Download Option
.
RS232. This setting must be enabled to download case data through the dedicated RS232 serial
port.
Printer. This setting must be enabled to print case data from the on-board printer.
USB. This setting must be enabled to download case data through the dedicated USB serial port.
WARNING
Use only XTRA USB memory sticks.
