Objet30 User Guide 6 Operating and Maintaining the Printer
DOC-34025 Rev. I 6-88
18. Discard the old filter
Caution:
The filter contains uncured printing material. Discard the filter in accordance
with applicable environmental regulations.
19. Cut and remove the cable tie securing the fitting at the end of the outlet
tube.
Figure 6-122 Tube with cable tie and fitting
20. Remove the fitting from the end of the tube.
21. Attach the fitting to the new filter.
Important:
To attach the filter, hold the fitting at the end of the feed tube in place and
turn the filter. Otherwise, the feed tube will be twisted and material might
leak.
Figure 6-123 Fitting attached to the new filter
