097-55501-01 Revision M – January 2009 TimeHub 5500 User’s Guide 111
Chapter 3 Installing the TimeHub 5500
Installing Modules into the Rear Panel
Master and Remote Shelves
For DS1 outputs, use DS1 Output Connector modules (part number 090-55591-01),
which are part of the DS1 Output Connector Module Kit (990-55591-01).
For CC outputs, use CC Output Connector modules (part number 090-55593-01),
which are part of the CC Output Connector Module Kit (990-55593-01).
To install the Output Connector module, align the pins on the rear of the module with
the connector on the shelf. Carefully seat the module onto the shelf. Tighten the six
captive screws to complete the installation.
Expansion Shelves
You can install up to 16 Output Connector panels in any of the locations on the rear
panel of an Expansion shelf, as shown in Figure 3-12. The Output Connector
module determines the type of output signal generated. Each Output Connector
module provides connections for 20 signals from the Output Driver cards. The
Output Connector modules for an Expansion shelf cannot be used on a
Master/Remote shelf.
For DS1 outputs, use Output Connector module p/n 090-55591-02, which is part of
the DS1 Output Module Kit (990-55591-02).
For CC outputs, use Output Connector module p/n 090-55593-02, which is part of
the CC Output Module Kit (990-55591-02).
To install the Output Connector module on an Expansion shelf, align the pins on the
rear of the module with the connector on the shelf. The vertical connector should be
facing to the left and the small connector should be on the bottom facing towards
the mating connector on the shelf. Carefully seat the module onto the shelf. Tighten
the captive screws to complete the installation.
Note: A label and the handle on each Master/Remote Output
Connector module denotes the type of output signal it generates.
Each DS1 Output Connector module is labeled “DS1” and has a black
handle; each CC Output Connector module is labeled “CC” and has a
blue handle.
Note: The part number label on each Expansion Output Connector
module denotes the type of output signal it generates. Each module
may also have silk-screened text denoting the output signal it
generates.
