88 TimeHub 5500 Users Guide 097-55501-01 Revision M – January 2009
Chapter 2 Engineering Ordering Information
Ordering and Parts List
Table 2-13 lists the components of an Expansion shelf.
Table 2-13. Expansion Shelf Basic Components
Item Part Number Quantity Included Items
Expansion shelf
kit
090-55505-02 1 Expansion shelf (090-55505-03)
Wire-wrap panel (190-55595-01)
Wire-wrap panel (190-55595-02)
Line terminator (190-55505-01) x 2
Gender changer (128-55505-01)
Connection cable (060-55505-01)
x 2
19 in. and 23 in. mounting
hardware
System manuals
CD with TimeScan THC and
complete TimeHub documentation
Expansion
Controller card
090-55545-01 1 (minimum)
2 (recommended)
Expansion Controller card
(090-55545-01)
Output Driver
cards
090-55581-01 1 (minimum)
2 (recommended)
up to 16 per
Expansion shelf
Output card (090-55581-01)
DS1 Output
module kit for
Expansion shelf
990-55591-02 1 (minimum)
2 (recommended)
up to 16 DS1 and
CC total per
Expansion shelf
DS1 Output module
(090-55591-02)
Round RJ-21 cable
(060-55591-02)
CC Output
module kit for
Expansion shelf
990-55593-02 1 (minimum)
2 (recommended)
up to 16 DS1 and
CC total per
Expansion shelf
CC Output module (090-55593-02)
Round RJ-21 cable
(060-55591-02)
5 MHz Output
Connector
module –
Expansion shelf
090-55596-02 1 per 5 MHz Output
group
NTP Output
Connector
modules:
Expansion shelf
090-55594-02 1 per NTP Server
card
Blank panels for
Output card
spaces
093-55598-02 16 minus number of
installed Output
cards
Optional to fill out output card
space
