097-55501-01 Revision M – January 2009 TimeHub 5500 User’s Guide 83
Chapter 2 Engineering Ordering Information
NTP Server Card
NTP Output Connector Modules
The NTP Output Connector modules provide an interface for all external signal
connections necessary for NTP operations (Figure 2-20). Two NTP Output
Connector modules are available for the Master shelf: a double-width Output
Connector module for Groups A, B, and C, and a single-width Output Connector
module for Group D. You can also use the single-width module in the 1–20 slot in
Group A, B, or C. One Output Connector module is available for use in an
Expansion shelf. Table 2-11 describes the LEDs on every module.
SFP A/B Green Off = No Ethernet connection
On (Green) = Ethernet link established
On (Flashing Green) = Ethernet activity (traffic)
Card A/S Green / Amber On (Green) = Standby
On (Flashing Green) = Active
On (Amber) = Standby (redundant) and not in
service
On (Flashing Amber) = Not in service
Table 2-10. LEDs on the NTP Server Card Front Panel (Continued)
Indicator Color Description
