274 TimeHub 5500 User’s Guide 097-55501-01 Revision M – January 2009
Chapter 6 Specifications
Factory Default Values
Depth: 11.6 in. (29.5 cm)
Weight: 14 lb (6.4 kg) empty
40 lb (18.2 kg) fully loaded
Wire-wrap Panel Mechanical
Mounting: 19 in. rack or 23 in. rack
(with supplied mounting ears)
Rack Mounting Position:Flush
5 in. (12.7 cm) offset
Width: 16.6 in. (42.2 cm)
Height: 5.25 in. (13.3 cm): wire-wrap module type
3.5 in. 8.9 cm): built-in wire-wrap pin type
Depth: 4.6 in. (11.7 cm)
Shelf and Wire-wrap Panel Environmental
Operating Temperature: 0 °C to +45 °C
Operating Humidity: 5% to 95%
Electromagnetic Compliance: FCC Part 15, Sub Part B, Class A
Certification
NEBS Level 3 compliant
Factory Default Values
This section describes the factory default values for parameters within the TimeHub
5500.
