097-55501-01 Revision M – January 2009 TimeHub 5500 Users Guide 89
Chapter 2 Engineering Ordering Information
User-Supplied Tools and Materials
Table 2-14 lists the accessories and spare parts that can be ordered separately.
User-Supplied Tools and Materials
User-supplied tools and materials are listed below.
Phillips-head screwdriver for installing the TimeHub 5500 shelf in a rack
Phillips-head or Pozidrive screwdriver for tightening or loosening captive screws
ESD wrist strap for installing cards
GMT fuse puller
Table 2-14. Accessories and Spare Parts
Item Part Number Description
Accessories
Blank panel for Clock
card
093-55598-01 Blank panel to cover slot of uninstalled input/clock card.
Master/Remote shelf only.
Blank panel for
Output card
093-55598-02 Blank panel to cover slot of uninstalled output card.
Master/Remote or Expansion shelf.
Blank panel for
Expansion Controller
card
093-55598-03 Blank panel to cover slot of uninstalled Expansion
Controller card.
Expansion shelf only.
Blank panel for
Output module
093-55599-01 Blank panel to cover space of unused output module.
Master/Remote shelf only.
Short blank panel for
Output module
093-55599-02 Blank panel to cover space of unused output module
slot. Covers one module space.
Expansion shelf only.
Long blank panel for
Output module
093-55599-03 Blank panel to cover space of unused Output module
slot. Covers two module spaces (one group).
Expansion shelf only.
Spare Parts
Wire-wrap input
module
090-55561-01 Wire-wrap input board.
Master/Remote shelf only.
High capacity
wire-wrap panel kit
093-55595-01 Wire-wrap panel with 160 outputs labeled A through D.
Includes kit to mount on 23 in. rack.
High capacity
wire-wrap panel kit
093-55595-02 Wire-wrap panel with 160 outputs labeled E through H.
Includes kit to mount on 23 in. rack.
