160 TimeHub 5500 User’s Guide 097-55501-01 Revision M – January 2009
Chapter 4 Testing and Configuring the TimeHub
Provisioning Inputs on a Master Shelf
"S1-CLK1:,090-55545-01-B,,D,,D0C1ZZ0AAA,299465"
"S1-CLK2:,090-55545-01-B,,D,,D0C1ZZ0AAA,299465"
"S1-OUT1A:,090-55581-01-B,,R4236A,00M16673,D0TPJNMAAA,106045,CC,DS1"
"S1-OUT2A:,090-55581-01-B,,R4236A,00M16687,D0TPJNMAAA,106045,CC,DS1"
"S1-OUT3B:,090-55581-01-B,,R4236A,00M16650,D0TPJNMAAA,106045,CC,DS1"
The first set of responses (those that begin with “S0-”) identify hardware in the
Master shelf. The second set of responses (those that begin with “S1-”) identify
hardware in the Expansion shelf. In this example:
The S1- indicates that address switch S1 on the Expansion shelf is set to 1. If
several shelves are connected, each shelf is identified by Sx, where x is value of
S1. Valid values are 1, 2, 3, and 4.
The S1-CLK1 line identifies the Expansion Controller card in the EC1 slot.
The S1-CLK2 line identifies the Expansion Controller card in the EC2 slot.
S1-OUT1A, S1-OUT2A, and S2-OUT3B identify that there are Output Driver
cards in slots 1A, 2A, and 3B. Each card has a CC and DS1 Output Connector
card installed on the back of the shelf.
Using TL1 Commands
Issue the following TL1 command:
RTRV-NETYPE-ALL;
A typical response is shown in the previous section.
Provisioning Inputs on a Master Shelf
After you connect the input signals to the Input/Alarm Connector card (described in
Connecting Timing Inputs, on page 119), you need to provision the TimeHub to
accept the inputs. The procedures in this section describe how to provision the
inputs using the TimeScan THC software and using TL1 commands. You must
connect a computer to the TimeHub as described in Establishing a Connection to
the TimeHub, on page 148 before you can perform this procedure.
To provision inputs using TL1 commands, see Using TL1 Commands, on page 163.
Using TimeScan THC
Use this procedure to provision the inputs for a Master shelf. If you are provisioning
inputs for a Remote shelf, see Provisioning Inputs on a Remote Shelf, on page 173.
Note: If the Management card contains firmware version 4328D, the
Expansion Controller cards are identified by ECC1 and ECC2 instead
of CLK1 and CLK2. The Clock cards on the Main shelf continue to
use CLK1 and CLK2.
