86 TimeHub 5500 Users Guide 097-55501-01 Revision M – January 2009
Chapter 2 Engineering Ordering Information
Ordering and Parts List
Ordering and Parts List
Table 2-12 lists the basic components that comprise a Master or Remote shelf.
Table 2-12. Master and Remote Shelf Basic Components
Item Part Number Quantity Included Items
Master shelf kit 990-55500-01 1 Master shelf (090-55501-03)
One Wire-wrap Input module
(090-55561-01)
One Wire-wrap panel
(190-55595-01)
19 in. and 23 in. mounting
hardware
System manuals
Management
card kit
990-55542-01 1
Management card
(090-55542-01)
DB9 connection cable
CD with TimeScan THC and
complete TimeHub documentation
Clock cards 090-5551x-0x 1 (minimum)
2 (recommended)
Quartz clock cards:
Quartz 5 input (090-55511-01)
Note: This clock does not support
Expansion shelves.
Quartz 9 input (090-55512-02)
Note: This clock supports
Expansion shelves.
Rubidium clock cards:
Rubidium 5 input (090-55513-01)
Note: This clock does not support
Expansion shelves.
Rubidium 9 input (090-55514-02)
Note: This clock supports
Expansion shelves.
Output Driver
cards
090-55581-01 1 (minimum)
2 (recommended)
up to 8 per Master/
Remote
Output card (090-55581-01)
DS1 Output
module kit
990-55591-01 1 (minimum)
2 (recommended)
up to 7 DS1 and
CC total per
Master/Remote
DS1 Output module
(090-55591-01)
Round RJ-21 cable
(060-55591-02)
