Chapter 3 Installing the TimeHub 5500
Installing Expansion Shelves
8. Connect the other end of this cable to the Expansion Link 2 IN connector on the
second Expansion shelf.
9. Repeat steps 5 through 8 for each additional Expansion shelf in the system.
10.Install a gender changer 128-55505-01 to the Expansion Link 2 OUT connector
on the last Expansion shelf in the system.
11.Install the Termination Connectors on the Expansion Link 1 OUT and Expansion
Link 2 OUT connectors on the last Expansion shelf in the system.
12.Tighten all connections.
Verifying the Installation
Perform the following procedure to verify the operation of the expansion shelf:
1. Establish either a serial or Ethernet communications connection to the TimeHub
5500.
2. Enter the command
RTRV-NETYPE-ALL (as shown in the following example) and
verify that the expansion shelf’s current hardware configuration is listed in the
response.
Command Example:
Issue the following TL1 command:
RTRV-NETYPE-ALL;
Or, using TimeScan THC:
1. Select Mode, Command Response from the main menu to open the Command
Response window.
2. Select TL1Commands, RTRV-NETYPE-ALL, or press F2 to send the
RTRV-NETYPE-ALL query.
A typical response is as follows:
SYMMBITS 04-10-19 11:14:33
M SV36 RTRV
"TSG:Symmetricom,5500,TSG"
"S0-IMC:,090-55542-01-A,,R4209C,J86746,D0TPN0NAAA,106063"
"S0-CLK1:,090-55514-02-A,,R4142B,J63939,D0TPKRJAAA,297083"
"S0-CLK2:,090-55512-02-A,,R4312A,K60716,D0TPVRKAAA,299460"
"S0-OUT1A:,090-55581-01-A,,R4236A,00M15316,D0TPJNMAAA,105045,CC,"
"S0-OUT2A:,090-55581-01-A,,R4236A,00M15320,D0TPJNMAAA,105045,CC,"
"S0-OUT3B:,090-55581-01-A,,R4236A,00M15317,D0TPJNMAAA,105045,CC,"
"S0-OUT4B:,090-55581-01-A,,R4236A,00M15360,D0TPJNMAAA,105045,CC,"
Note: The active clock may take from three to ten minutes to do a
complete inventory depending on the number of expansion shelves
present.
