097-55501-01 Revision M – January 2009 TimeHub 5500 Users Guide 171
Chapter 4 Testing and Configuring the TimeHub
Testing an Expansion Shelf
Or, using TimeScan THC:
1. Select Mode, Command Response from the main menu to open the Command
Response window.
2. Select TL1Commands, RTRV-NETYPE-ALL, or press F2 to send the
RTRV-NETYPE-ALL query.
A typical response is as follows:
SYMMBITS 04-10-19 11:14:33
M SV36 RTRV
"TSG:Symmetricom,5500,TSG"
"S0-IMC:,090-55542-01-A,,R4209C,J86746,D0TPN0NAAA,106063"
"S0-CLK1:,090-55514-02-A,,R4142B,J63939,D0TPKRJAAA,297083"
"S0-CLK2:,090-55512-02-A,,R4312A,K60716,D0TPVRKAAA,299460"
"S0-OUT1A:,090-55581-01-A,,R4236A,00M15316,D0TPJNMAAA,105045,CC,"
"S0-OUT2A:,090-55581-01-A,,R4236A,00M15320,D0TPJNMAAA,105045,CC,"
"S0-OUT3B:,090-55581-01-A,,R4236A,00M15317,D0TPJNMAAA,105045,CC,"
"S0-OUT4B:,090-55581-01-A,,R4236A,00M15360,D0TPJNMAAA,105045,CC,"
"S0-OUT5C:,090-55581-01-A,,R4236A,00M15358,D0TPJNMAAA,105045,CC,"
>
SYMMBITS 04-10-19 11:14:33
M SV36 COMPLD
"S1-CLK1:,090-55545-01-B,,D,,D0C1ZZ0AAA,299465"
"S1-CLK2:,090-55545-01-B,,D,,D0C1ZZ0AAA,299465"
"S1-OUT1A:,090-55581-01-B,,R4236A,00M16673,D0TPJNMAAA,106045,CC,DS1"
"S1-OUT2A:,090-55581-01-B,,R4236A,00M16687,D0TPJNMAAA,106045,CC,DS1"
"S1-OUT3B:,090-55581-01-B,,R4236A,00M16650,D0TPJNMAAA,106045,CC,DS1"
The first set of responses (those that begin with “S0-”) identify hardware in the
Master shelf. The second set of responses (those that begin with “S1-”) identify
hardware in the Expansion shelf. In this example:
The S1- indicates that address switch S1 on the Expansion shelf is set to
1. If several shelves are connected, each shelf is identified by Sx, where x
is value of S1. Valid values are 1, 2, 3, and 4.
The S1-CLK1 line identifies the Expansion Controller card in the EC1 slot.
The S1-CLK2 line identifies the Expansion Controller card in the EC2 slot.
S1-OUT1A, S1-OUT2A, and S2-OUT3B identify that there are Output
Driver cards in slots 1A, 2A, and 3B. Each card has a CC and DS1 Output
Connector card installed on the back of the shelf.
3. Enter the command
SW-DX-EQPT to switch the inactive Clock card to the active
state.
Note: If the Management card contains firmware version 4328D, the
Expansion Controller cards are identified by ECC1 and ECC2 instead
of CLK1 and CLK2. The Clock cards on the Main shelf continue to
use CLK1 and CLK2.
