Index
Topcon HiPer+ Operator’s Manual
Index
Power 2-2
board 1-12
charger 2-4
external 2-3
internal 2-2
management 2-15, 2-16–2-20
Power board file 4-24, 4-26
R
Radio configuration 2-30
RAM file 4-24, 4-25, 4-27, 4-28
Range D-1
Real-time kinematic 1-2
see also RTK 1-2
REC LED 4-2
green 4-2
orange 4-2
red 4-2, 4-3
Receiver modes 4-20
see also EIM
see also Normal Mode
extended
4-7–4-8
sleep mode 4-20
zero power 4-20
Receiver setup
w/ internal antenna 3-2
Recording interval 2-25
Reset key 4-2
Rover
configuration
3-9–3-10,
3-11–3-12
setup 3-17, 3-17–3-21
RTK 1-2, 3-12
base station setup 3-12
w/ external modem 3-17
package contents 1-7
rover setup 3-17
RX LED 4-6
blink pattern 4-6
green 4-6
no light 4-6
orange 4-6
S
Satellites
in view 1-4
Scripts 2-32
create A-1
Security parameters 2-47
Serial number 1-14, 3-7
Set baud rate
115200 1-16, 2-6, 2-8, 4-23,
5-10
19200 3-16, 3-20
38400 2-30, 2-36, 2-38, 3-16,
3-20
9600 4-3
SHMM 1-16, 1-17, 3-3
Slant height measure mark
see SHMM
Sleep mode
4-20
Software 1-8
ActiveSync 1-8
BTCONF 1-8
FLoader 1-8, 4-23
PC-CDU 1-8, 2-10–2-39
PDLCONF 1-8, 2-30,
2-32–2-38
Pinnacle 1-8
radio configuration 1-8, 2-30
Start/stop data recording 4-2
STAT LED 4-2, 4-7
blink pattern 4-2, 4-7–4-8
EIM 4-7
green 4-2
orange 4-2
red 4-2
Static survey 3-5–3-8
configuration 3-6
MINTER parameters 3-6
Stop and Go survey 3-9
configuration 3-9
