JackingInstructions

CAUTION

Whenchangingattachments,tiresorperformingotherservice,use

correctjacksandsupports.Makesuremachineisparkedonasolid,

levelsurfacesuchasaconcreteoor.Priortoraisingmachine,

removeanyattachmentsthatmayinterferewiththesafeandproper

raisingofthemachine.Alwayschockorblockwheels.Usejack

standstosupporttheraisedmachine.Ifthemachineisnotproperly

supportedbyjackstands,themachinemaymoveorfall,whichmay

resultinpersonalinjury.

JackingtheFrontEnd(Figure2)

g008996

Figure2

1.Framejackingpoint

1.Setparkingbrakeandchockbothreartirestopreventthemachinefrom

moving.

2.Positionjacksecurelyundertheframe,justtotheinsideofthefronttire.

Makesurethatthejackdoesnotcontacthydraulicliftcylinder.Jackfront

wheelofftheground.

3.Oncethemachineisraised,positionjackstandundertheframeascloseto

thewheelaspossibletosupportthemachine.

Safety:SafetyInstructions

Page1–6

Groundsmaster

5900&5910

16227SLRevB
