ServiceandRepairs

CAUTION

Neverinstallorworkonacuttingdeckorliftarmwiththeengine

running.Alwaysstopengineandremoveignitionkeyrst.

FrontCuttingDeck

g299333

Figure322

1.Frontcuttingdeck5.Damperassembly

9.Thrustwasher(1perliftarm)

2.Hydraulicmotor

6.HOCchain(1perliftarm)10.Locknut(2perliftarm)

3.Liftarmassembly−LH7.Capscrew(2perliftarm)11.Plate(1perliftarm)

4.Clevispin(1perliftarm)8.Flatwasher(2perliftarm)

12.Frontcuttingdeckpositionswitch

SeeFrontDeckLiftArms(page7–17)forliftarmremoval,installationand

serviceinformation.

Groundsmaster

5900&5910

Page8–3

CuttingDecks:ServiceandRepairs

16227SLRevB
