CuttingDeckMotor
6
2
13
11
15
14
5
12
4
3
1
10
9
7
8
37 to 44 N·m
(27 to 33 ft−lb)
g288021
Figure104
FrontDeckMotorShown
1.Cuttingdeckmotor
6.Hydraulichose−pressure11.Washer
2.Flangeheadscrew(2)7.Hydraulictting12.Spider
3.45ºhydraulictting
8.Hydraulichose−casedrain13.Motormount
4.Hydraulichose−return
9.Woodruffkey14.Spindleassembly
5.Hydraulictting10.Couplerhub
15.Hexnut
Thehydraulicmotorsusedonallcuttingdecksarethesame.
CuttingDeckMotorRemoval(Figure104)
1.Parkmachineonalevelsurface,lowercuttingdecksfully,disengagePTO
andstopengine.Removekeyfromkeyswitch.
2.ReadtheGeneralPrecautionsforRemovingandInstallingHydraulicSystem
Components(page5–73).
3.Topreventcontaminationofhydraulicsystemduringdeckmotorremoval,
thoroughlycleanexteriorofmotor.
4.Disconnecthydrauliclinesfromdeckmotor.Putcapsorplugsonttingsand
hosestopreventcontaminationofhydraulicsystem.Labelhydrauliclines
forproperassembly.
5.Removetwo(2)angeheadscrewsthatsecurehydraulicmotortocutting
deck.
6.Lifthydraulicmotorfromcuttingdeck.
7.Ifhydraulicttingsaretoberemovedfromdeckmotor,markttingorientation
toallowcorrectassembly.RemovettingsfrommotoranddiscardO–rings.
HydraulicSystem:ServiceandRepairs
Page5–118
Groundsmaster
®
5900&5910
16227SLRevB
