Toro Groundsmaster 5910 Series User Manual

HydraulicReservoir
9
8
15
16
14
17
18
19
20
22
24
1
3
5
4
6
7
10
21
23 35 34
33
29
29
25
11
28
2
26
27
30
31
32
143 to 155 N·m
(105 to 115 ft−lb)
18 to 19 N·m
155 to 171 in−lb
5 to 6 N·m
(44 to 55 in−lb)
5 to 6 N·m
(44 to 55 in-lb)
12
13
7
6
g287876
Figure79
1.Bushing
13.O−ring
25.Flangeheadscrew
2.Elbowtting14.Standpipe(4)
26.Hoseclamp
3.Latchplate15.Dipstick27.Hose
4.Socketheadscrew(2)16.Bushing(4)28.O−ring
5.Magneticcatch17.Hydraulicreservoir29.Hoseclamp
6.Hingebracket(2)18.Capscrew30.Suctionhose
7.Pushnut(2)
19.Washer
31.Cabletie(2)
8.Socketheadscrew(2)20.Spacer
32.Hoseguard
9.T ankcover21.Drainplug33.Tanksupport
10.Rod22.T ankstrainer
34.Tinnermannut(2)
11.O−ring23.Flangenut(2)
35.Flangeheadscrew
12.Reservoircap24.Reservoirholddown
Groundsmaster
®
5900&5910
Page5–83
HydraulicSystem:ServiceandRepairs
16227SLRevB
