Toro Groundsmaster 5910 Series - Steering Control Valve Service (for Machines Serial Number below 40345000)

SteeringControlValveService(Formachinesserialnumberbelow
40345000)
16 to 18 N·m
(140 to 160 in−lb)
17 N·m
(150 in−lb)
3
5
6
4
7
1
2
19
20
8
9
10
11
12
13
14
15
21
22
23
16
17
18
g288163
Figure121
1.Steeringvalvehousing9.Capscrew(7)17.Gerotordrive
2.Dustseal10.Endcap18.Wearplate
3.O−ring11.O−ring
19.Bearingrace
4.Spool12.Sealring
20.Thrustbearing
5.Springretainingring13.O−ring
21.Plug
6.Pin
14.Gerotor22.O−ring
7.Sleeve15.O−ring23.Checkball
8.Centeringsprings/spacers16.Quadseal
Note:Forsteeringcontrolvalverepairprocedures,seetheEatonPartsand
RepairInformation.
Groundsmaster
®
5900&5910
Page5–137
HydraulicSystem:ServiceandRepairs
16227SLRevB
