Toro Groundsmaster 5910 Series User Manual

Groundsmaster5900/5910,Drawing130-2420RevA,Sheet1of1
16227SLRevB
PageA–3
HydraulicSchematic
1.5 CID
P1
P2
M1
M2
CDFRONT DECK
G1
600
PSI
ISP01 1CL
PRV
SQ
110 PSI
OR2 .025”
LC2
10 PSI
RV
1.5 CID
3000 PSI
PRV
3000 PSI
P1
P2
M1
M2
LEFT DECK
OR1
.063”
ISP01 1CL
RV
LC2
CD
OR1
G1
10.6 GPM
21.7 GPM
1.5 CID
M5
600
PSI
600
PSI
1.03
CID
2.11
CID
2.11
CID
P1
P2
M1
M2
RIGHT DECK
G1
OR1
.063”
ISP01 1CL
SQ
110 PSI
OR2 .025”
LC2
10 PSI
CD
21.7 GPM
SQ
110 PSI
OR2 .025”
10 PSI
PRV
2000 psi
RV
4.15 CID
ENGINE RATED
SPEED: 2530 RPM
B
MB
MA
A
M4
3M2L
5080
PSI
500
PSI
5080
PSI
290
PSI
36
PSI
0.032” 0.032”
S1S2
E
L4
42.7 GPM
M14
RETURN FILTER
BREATHER
FORWARD
REVERSE
TRACTION PUMP
6.1 CID
STEER CYLINDERS
BORE: 1.25”
STROKE: 6.00”
ROD: 0.75”
EP
LR
T
LH WING DECK LIFT
BORE: 2.25”
STROKE: 11.38”
ROD: 1.12”
EXTEND TO: LIFT
C3
OR3
STEERING
UNIT
S2
S4
S5
S3
OR4
S6
.138”
RV2
1500 PSI
RH WING DECK LIFT
BORE: 2.25”
STROKE: 11.38”
ROD: 1.12”
EXTEND TO: LIFT
CENTER DECK LIFT
BORE: 2.25”
STROKE: 4.38”
ROD: 1.12”
EXTEND TO: LIFT
S1
2C4C
G3
.088”
.046”
OR2
.055”
OR5
S7
S9
S8
OR6
.055”
OR7
.088”
5 PSI
CV1
6C5C
G4
CL
50 PSI
4 PSI
CV3
S10
G
17.1 CID
A1
13 CID
R
M5
M2M1
LEFT REAR
BRK
HP
0.083 CID
MV
RV
400 PSI
BRAKE RELEASE
MANIFOLD
BRK
CH
CH3
L
.030”
OR8
100 PSI
PD3
100 PSI
PD4
100 PSI
PD5
RV1
CV1 CV2
17.1 CID
A1
A2
R
1
X
17.1 CID
A2
R
1
X
17.1 CID
M8
M7
M6
LEFT FRONT
PD2
CV5CV4
.314”
PD6
60 PSI
CH1
SH
OR1
.314”
100 PSI
PD1
SV
CV3
TRACTION MANIFOLD
TSCD1 M3 M4 CD2 CH
M9
P1
P2
RIGHT FRONT
M10
170 PSI5 PSI
OR3
0.5 GPM
FR
60 PSI
OR2
.314”
100 PSI
1
OR4 .030”
13 CID
1
R
L
RIGHT REAR
RV1
2100 PSI
LC
80 PSI
RV3
STEERING / DECK LIFT MANIFOLD
340 PSI
CH2TP1
G1
CF
LS
G2
OR1
.030”
CV2
AM3
g299963
