Toro Groundsmaster 5910 Series User Manual

InfoCenterDisplay
1
2
g288346
Figure138
1.Operatorcontrolconsole2.InfoCenterDisplay
TheGroundsmasterInfoCenterDisplayisaLCDdevicethatislocatedinthe
Operatorcontrolconsole.TheInfo-Centerdisplayprovidesinformationfor
themachineoperatorduringmachineoperation,provideselectricalsystem
diagnosticassistancefortechniciansandallowsinputsforadjustablemachine
settings.
PowerfortheInfoCenterisavailablewhenthemainpowerrelayisenergized
(keyswitchisintheSTARTorRUNposition).A2Ampfuse(F−B5)protectsthe
Info-Centerpowercircuit.ACANbusnetworkinvolvingthemasterandslave
ToroElectronicControllers(TECs),theYanmarengineECUandtheInfoCenter
isusedtocommunicatemachineinformationtoandfromtheInfo-Centerdisplay.
Note:TheTECcontrollersandtheInfoCenterDisplayusedonthe
Groundsmaster5900and5910arematchedforcorrectmachineoperation.If
anyofthesecomponentsarereplacedforanyreason,systemsoftwareneedsto
bereprogrammed(contactanAuthorizedToroDistributorforassistance).
Groundsmaster
®
5900&5910
Page6–9
ElectricalSystem:InfoCenterDisplay
16227SLRevB
