Toro Groundsmaster 5910 Series - Piston (Traction) Pump Control Solenoid Coils

Piston(Traction)PumpControlSolenoidCoils
1
2
3
g288613
Figure267
1.Pistonpump3.Reversesolenoidcoil
2.Forwardsolenoidcoil
1
1
2
2
2
2
3
3
5 N·m
(44 in-lb)
5 N·m
(44 in-lb)
g288614
Figure268
1.Solenoidcoil3.Coilnut
2.O−ring
Thepiston(traction)pumpusesanelectroniccontrolassemblytochangethe
positionoftheswashplateandthepumpdisplacement.Electricaloutputsfrom
themachineTECcontrollerareprovidedtotwo(2)solenoidcoilsforpump
control.OnesolenoidcontrolstheAsidepumpdisplacement(forwarddirection)
andtheothercontrolstheBsidepumpdisplacement(reversedirection)The
pistonpumpcontrolassemblyisattachedtotheleftsideofthepistonpump
(Figure268).
Note:Toassistintroubleshooting,thepistonpumpsolenoidcoilscanbe
exchangedbecausetheyareidentical.Iftheproblemfollowstheexchangedcoil,
aproblemwiththecoilislikely.Iftheproblemremainsunchanged,something
otherthanthesolenoidcoilisatfault(e.g.tractionpedal,tractionpedalposition
sensor,circuitwiring,hydraulicproblem).
