ResistorAssemblies

Three(3)differentresistorsareusedonallGroundsmaster5900/5910machines.

Eachresistorhasadifferentresistanceratingandlocationonthemachine.

1 2

g288603

Figure257

1.Resistorassembly

2.Endofresistorbody

g288604

Figure258

1.Frontpowercenter(behindoperatorseat)

3.Diodeblock1

2.Diodeblock24.2Kohmresistor

1 2

g288605

Figure259

1.Miniresistor

2.Endofresistorbody

ElectricalSystem:ComponentTesting

Page6–116

Groundsmaster

5900&5910

16227SLRevB
