TractionCircuit
1
2
3
4
5
6
7
8
9
10
11
12
g287894
Figure86
1.Piston(traction)pump5.RHfrontwheelmotor9.Chargereturntoreservoir−out
2.Gearpump
6.RHrearwheelmotor
10.Casedraintoreservoir−out
3.LHfrontwheelmotor
7.LHrearwheelmotor
11.Brakereleasemanifold
4.Tractionmanifold8.Chargepressure−in12.Fromsteering/liftmanifold−in
Figure86illustratesthecomponentsthatareusedintheGroundsmastertraction
circuit.Proceduresforremoval,installationanddisassembly/assemblyofthese
componentsareprovidedonthefollowingpagesofthischapter.
Groundsmaster
®
5900&5910
Page5–93
HydraulicSystem:ServiceandRepairs
16227SLRevB
