WingCuttingDeckLiftCylinderService
12
11
9
10
7
6
5
8
4
3
1
2
13
14
15
16
12
11 9 10
76
5
8
431
2
13
14 1516
176 N·m
(130 ft−lb)
g288201
Figure129
1.Barrelwithclevis7.Back−upring13.Wearring
2.Externalcollar8.Head14.Pistonseal
3.Shaftwithclevis9.O−ring15.Steelring−cushion
4.Dustseal
10.Cushion
16.Wearring
5.Shaftseal
11.Piston
6.O−ring
12.Locknut
WingCuttingDeckLiftCylinderDisassembly(Figure129)
1.Removeoilfromliftcylinderbyslowlypumpingthecylindershaft.After
removingoilfromcylinder,plugbothportsandcleantheoutsideofthe
cylinder.
IMPORTANT
Preventdamagewhenclampingthecylinder’sbarrelintoavise;
clamponthebarrelclevisonly.Donotcloseviseonbarrel.
2.Mountliftcylinderinaviseequippedwithsoftjawsbyclampingonthe
barrelclevis.
3.Useaspannerwrenchtoloosenandremovecollarfrombarrel.
4.Extractshaftwithhead,cushionandpistonbycarefullytwistingandpulling
ontheshaft.
HydraulicSystem:ServiceandRepairs
Page5–150
Groundsmaster
®
5900&5910
16227SLRevB
