TurnSignalSwitch

g288527

Figure222

1.Operatorcontrolconsole

2.Turnsignalswitch

Theturnsignalswitchislocatedontheconsolearm(Figure222).Whentheturn

signalswitchisdepressed(leftorright),powerissenttotheashermoduleto

illuminatethecorrespondingsignallights.Thesignallightswillcontinuetoash

untiltheswitchisreturnedtotheOFF(center)position.Theturnsignalswitch

receivespowerfromfuseF−B3(15Amp).

Testing

1.Parkmachineonalevelsurface,lowercuttingdecksandstopengine.

Removekeyfromkeyswitch.

2.Turnbattery−disconnectswitchtotheOFFposition.

3.Disassembletheconsolearmtogainaccesstotheswitch(seeConsole

Arm(page7–35)).

4.Disconnectmachinewireharnessconnectorfromtheswitchbeingtested.

g288528

Figure223

BackofSwitch

5.TheswitchterminalsaremarkedasshowninFigure223.Thecircuitlogic

ofthethrottleswitchisshowninbelowtable.Withtheuseofamultimeter

(ohmssetting),theswitchfunctionsmaybetestedtodeterminewhether

continuityexistsbetweenthevariousterminalsforeachswitchposition.

Verifycontinuitybetweenswitchterminals.

SWITCHPOSITIONCLOSEDCIRCUITSOPENCIRCUITS

RIGHTTURN

2+1and5+42+3and5+6

OFFNONE

ALL

LEFTTURN2+3and5+62+1and5+4

6.Replacetheswitchiftestingdeterminesthatitisfaulty.

7.Iftheswitchtestscorrectlyandacircuitproblemstillexists,checkthewire

harnesses(seeAppendixA(pageA–1)).

ElectricalSystem:ComponentTesting

Page6–82

Groundsmaster

5900&5910

16227SLRevB
