Adjustments
CuttingDeckPositionSwitchAdjustment
Anormallyopenproximityswitchislocatedneartheframepivotofthefrontright
liftarmandeachwingdeckliftarmtoinformtheslavecontrollerofthecurrent
cuttingdeckposition.
Adjustment
2.4 to 3.9 mm
(0.095 to 0.155 in)
1
2
3
4
g288430
Figure187
1.Frontliftarm3.Switchbracket
2.Positionswitch
4.Sensingplate
1.Parkmachineonalevelsurfacewiththecuttingdeckslowered.Stopengine
andremovekeyfromthekeyswitch.
2.Allcuttingdeckpositionswitchesshouldhavea2.3to3.8mm(0.090to
0.150in)clearancebetweenthesensingeyeofthepositionswitchandthe
sensingplate.
Note:Thepositionswitchesusedonmachineswithserialnumbersabove
316000200includeanLEDonthecableendoftheswitchbody.The
switchLEDshouldbeilluminated(switchclosed)whenthecuttingdecks
arelowered.
ElectricalSystem:Adjustments
Page6–46
Groundsmaster
®
5900&5910
16227SLRevB
