FuelSystem
11
12
13
13
13
14 15 16
17
18
1
2
3
4
5
8
9
10
10
21
22
23
24
25
26
19
20
6
7
g287551
Figure19
1.Fueltank
10.Bushing(2)
19.Fuelhose−toventtube
2.Fittingcover
11.Standpipe−return
20.Bushing
3.Screw(3)12.Standpipe−supply21.Elbowtting−vent
4.Cap13.Clamp(3)22.Clamp(2)
5.Gasket14.Fuelhose−returnfromlter23.Panelfastener(4)
6.Fuelsender15.Fuelhose−supplytoseparator24.T ankholddown
7.Gasket
16.Flangeheadscrew
25.Flangeheadscrew(2)
8.Lockwasher(5)17.Clamp26.Flangenut(2)
9.Screw(5)
18.Flangenut
DANGER
Becausedieselfuelishighlyammable,usecautionwhenstoringor
handlingit.Donotsmokewhilellingthefueltank.Donotllfuel
tankwhileengineisrunning,hotorwhenmachineisinanenclosed
area.Alwaysllfueltankoutsideandwipeupanyspilleddieselfuel
beforestartingtheengine.Storefuelinaclean,safety−approved
containerandkeepcapinplace.Usedieselfuelasanenginefuel
only;notforanyotherpurpose.
Groundsmaster
®
5900&5910
Page4–17
YanmarDieselEngine:ServiceandRepairs
16227SLRevB
