Toro Groundsmaster 5910 Series User Manual

SteeringandCuttingDeckLiftCircuits
12
1
2
3
4
5
6
8
8
9
10
11
7
g288146
Figure115
1.Piston(traction)pump5.Steeringcylinder(2)9.Suctionfromreservoir−in
2.Gearpump6.Frontdeckliftcylinder−RH
10.Returntoreservoir−out
3.Steering/liftcontrolmanifold7.Frontdeckliftcylinder−LH11.Supplytobrakereleasemanifold−
out
4.Steeringcontrolvalve8.Wingdeckliftcylinder(2)
12.Returntooilcooler−out
Figure115illustratesthecomponentsthatareusedintheGroundsmaster
steeringandcuttingdeckliftcircuits.Proceduresforremoval,installationand
disassembly/assemblyofthesecomponentsareprovidedinthefollowingpages
ofthischapter.
HydraulicSystem:ServiceandRepairs
Page5–130
Groundsmaster
®
5900&5910
16227SLRevB
