Fuses
Circuitprotectionforthe24VDCsystemincludesa100Ampmegafuse(see
MegaFuses(page6–56))anda5Ampfuselocatedontherearpowercenter.
Theentire12VDCsystemisprotectedbya60Ampmegafuse(seeMegaFuses
(page6–56)).Theindividual12Volttractionunitcontrolcircuitsareprotectedby
avarietyofsmalleramperagefuseslocatedatthefrontorrearpowercenters.
Thefrontpowercenterislocatedbehindtheoperatorseatandtherearpower
centerisintherightrearcornerofenginecompartment.
Groundsmaster5910machines(withcab)includeadditional12VCDcircuit
protectionviaa60Ampmegafuse(seeMegaFuses(page6–56)),a10Amp
fusefortheradioattachedtotherightsideofthecoolersupportframeandeight
(8)fusesinafuseblocklocatedinthecabheadliner.
FuseIdentication,LocationandFunction
1
2
4
5
6
3
FRONT
g288441
Figure197
1.60Ampmegafuseholder(tractionunit)4.25Ampfuse(YanmarECU)
2.Fuse/Diodeholderbase5.5Ampfuse(24Voltalternator)
3.Fuse/Diodeholdercover6.Diode(24Voltalternator)
Raisehoodtoaccessrearpowercenterinrightrearcornerofengine
compartment(Figure197).
•A25AmpfusesuppliespowertoYanmarECU.
•A5Ampfusesuppliespowerto24Voltalternatorsenseterminal.
