FuseIdentication,LocationandFunction(continued)
g288442
Figure198
1.Frontpowercenter(behindoperatorseat)2.Frontfuseblock
FRONT
A B C D
7.5 7.5 7.5 2
7.5 7.5 7.5 2
10 15 10 10
10 10 30 10
2 2
1
g288443
Figure199
FrontPowerCenterFuseBlock
Removecoverfromfrontpowercenterbehindoperatorseattoaccessfuses
(Figure198andFigure199).
•FuseF−A1(7.5Amp)suppliespowertoMasterTECoutputs11to14.
•FuseF−B1(7.5Amp)suppliespowertoMasterTECoutputs1to4.
•FuseF−C1(7.5Amp)suppliespowertoMasterTECoutputs5to10.
•FuseF−D1(2Amp)supplieslogicpowertoMasterTEC.
•FuseF−A2(7.5Amp)suppliespowertoSlaveTECoutputs11to14.
•FuseF−B2(7.5Amp)suppliespowertoSlaveTECoutputs1to4.
•FuseF−C2(7.5Amp)suppliespowertoSlaveTECoutputs5to10.
•FuseF−D2(2Amp)supplieslogicpowertoSlaveTEC.
•FuseF−A3(10Amp)suppliespowertotheEUroadlightkithazardcircuit.
•FuseF−B3(15Amp)suppliespowertotheroadlights.
•FuseF−C3(10Amp)suppliespowertothepowerpoint.
•FuseF−D3(10Amp)suppliespowertokeyswitchterminals1and6.
•FuseF−A4(10Amp)suppliespowertotheairrideseatsuspension.
•FuseF−B4(10Amp)suppliespowertothebrakelights.
ElectricalSystem:ComponentTesting
Page6–58
Groundsmaster
®
5900&5910
16227SLRevB
