HydraulicOilTemperatureSender

123 4

g288596

Figure254

1.Hydraulictractionmanifold

3.Hydraulicoiltemperaturesender

2.Adaptertting4.O−ring

Thehydraulicoiltemperaturesenderisattachedtothehydraulictraction

manifoldinportTS(Figure254).

Testing

1.Locatehydraulicoiltemperaturesenderanddisconnectwireharness

connectorfromtemperaturesender.

2.Thoroughlycleanhydraulictractionmanifoldaroundtemperaturesender.

Removesenderfromtheadaptertting.

g288597

Figure255

3.Putsensingendofsenderinacontainerofoilwithathermometerandslowly

heattheoil(Figure255).

CAUTION

Handlethehotoilwithextremecaretopreventpersonalinjuryorre.

Groundsmaster

5900&5910

Page6–113

ElectricalSystem:ComponentTesting

16227SLRevB
