Toro Groundsmaster 5910 Series User Manual

TRACTIONPEDAL
1
2
3
4
5
6
g288309
Figure145
1.Button14.Button4
2.Button25.Button5
3.Button36.Tractionpedalscreen
Thetractionpedalscreenliststhecalibrationvaluesstoredinthemaster
controllerfordifferenttractionpedalpositions(tractionpedalpositionsensor).
Thisscreenalsoidentiesthatthetractionpedalpositionsensorcalibration
hasbeencompleted.
Tobeginthetractionpedalpositionsensorcalibrationprocess,pressbutton1
(seeTractionPedalPositionSensorCalibration(page6–51)).
R NR NF F
2.23 V
NR NF
2.25 V
2.33 V2.18 V
CALIBRATED
1
2
3
4
5
6
7
g288310
Figure146
1.Positionindicatorbar5.Forwardswitchstateicon
2.Neutraltoreverse(opentoclose)voltage6.Neutraltoforward(opentoclose)voltage
3.Reverseswitchstateicon7.Neutralcentertargetvoltage
4.Voltageforpedalinpresentposition
ElectricalSystem:InfoCenterDisplay
Page6–16
Groundsmaster
®
5900&5910
16227SLRevB
