WheelMotorService

g287965

Figure97

(RearMotorShown)

1.Flangenut(6)4.Sealkit

2.Rotatinggroup

5.Cam

3.Radialclip(6)

ThefrontwheelmotorsonGroundsmaster5900/5910machineslookidentical

butcontainuniqueinternalcomponentsforrightsideandleftsideapplication.To

avoidinterchangingfrontwheelmotorsonthemachine,labelfrontwheelmotors

RIGHTandLEFTforassemblypurposes.Therightandleftrearwheelmotors

onthemachinesareidentical.Usethemanufacturersidenticationplateonthe

motortoidentifythecorrectpartsandserviceinformationforthemotor.

Groundsmaster

5900&5910

Page5–107

HydraulicSystem:ServiceandRepairs

16227SLRevB
