Toro Groundsmaster 5910 Series User Manual

MachineFaults
90 726.7 24 27
5 708.5 5.4 4
92 517.1 517.0 3
91 517.1 517.0 4
12 516.9 472.7 2
97 516.9 516.9 1
g287507
Figure9
MachinefaultsaregeneratedbytheToroElectronicControllers(TEC)toidentify
anelectricalsystemmalfunction(fault)thatoccursduringmachineoperation.
Whenanmachinefaultoccurs,anaudiblealarmwillsoundandtheInfoCenter
willdisplayinformationaboutthefaultlogged.Machinefaultscanbeviewedvia
theInfoCenterDiagnosticScreenFaultViewer(Figure9).SeeDIAGNOSTICS
SCREENS(page6–22)foradditionalinformation.
TheYanmarEngineControlUnit(ECU)canalsogenerateelectricalfaults.The
faultsgeneratedbytheECUarespecictotheengine(seeEngineFaults(page
3–27)foradditionalinformation).
Machinefaults1through4arespecictothetractionpedalpositionsensor.For
tractionpedalpositionsensorproblems:
1.UsetheInfoCenterDisplaytocheckthedifferenttractionpedalposition
sensorpositions(seeDIAGNOSTICSSCREENS(page6–22)).
2.Recalibratethetractionpedalpositionsensor(seeTractionPedalPosition
SensorCalibration(page6–51)).
3.Testthetractionpedalpositionsensoranditscircuitwiring(seeTesting
(page5–36)).
Faultcode5isspecictothemasterTECoutputsignalsbeingsenttothe
traction(piston)pumpforwardandreversesolenoids.Thisfaultmayindicatean
internalproblemwiththemasterTECrequiringreplacementandreprograming.
ContactanAuthorizedToroDistributorforassistance.
Machinefaults6through40identifyproblemswithinputs(e.g.sensorsand
switches)totheTECcontrollers.Forinputproblems:
1.UsetheInfoCenterDisplaytocheckthedifferentswitchpositions(see
DIAGNOSTICSSCREENS(page6–22)).
2.Testthespeciccomponentanditscircuitwiring(seeTesting(page5–36)).
Machinefaults81through100identifygeneralmachinefaultsthatrequire
speciccorrectiveactionassuggestedinthefollowingtable:
FaultCode
FaultDescription
ServiceSuggestions
Testtractionpedalpositionsensor
supplypowerfromTEC.
Testtractionpedalpositionsensorand
circuitwiring.
1
PedalSensorVoltageOutofRange.
Replacetractionpedalpositionsensor.
2
PedalSensorAnalogandDigital
SignalsConict.
Replacetractionpedalpositionsensor.
Groundsmaster
®
5900&5910
Page3–23Troubleshooting:
16227SLRevB
