FusibleLinkHarness
g288437
Figure194
1.Startermotorshieldremoved)
2.Fusiblelinkharness
FUSIBLE LINK (14 GAUGE)
FUSIBLE LINK (16 GAUGE)
P01
STARTER B+
P02
TO MAIN HARNESS P22
g288438
Figure195
YourGroundsmasterusestwo(2)fusiblelinksforcircuitprotection.Thesefusible
linksarelocatedinaharnessthatconnectsthestarterB+terminaltothewire
harness(Figure195).Ifeitheroftheselinksshouldfail,currenttotheprotected
circuitswillbeinterrupted.RefertoAppendixA(pageA–1)foradditionalfusible
linkinformation.
Testing
1.Parkmachineonalevelsurface,lowercuttingunitsandstopengine.
Removekeyfromkeyswitch.
2.Raisehoodandturnthebattery−disconnectswitchtotheOFFposition.
3.Removetheshieldoverthestartermotor.
4.Locateandunplugfusiblelinkconnectorfrommachinewireharness.
5.Useamultimetertomakesurethatcontinuityexistsbetweenthefusible
linkterminals.
6.Ifeitherfusiblelinkisopen,replacethefusiblelinkharness.
Note:Itisnotrecommendedtoreplaceindividualfusiblelinkconductorsof
thefusiblelinkharness.Ifanyoftheharnesslinksareopen(failed),replace
theentirefusiblelinkharness.
ElectricalSystem:ComponentTesting
Page6–54
Groundsmaster
®
5900&5910
16227SLRevB
