ComponentTesting

Foraccurateresistanceand/orcontinuitychecks,electricallydisconnectthe

componentbeingtestedfromthecircuit(e.g.unplugthewireharnessconnector

fromthekeyswitchbeforedoingacontinuitycheckoftheswitch).

Note:Forenginecomponenttestinginformation,seetheYanmarModel

4TNV98CT−NTRLYanmarServiceManualorYanmarTroubleshootingManual.

CAUTION

Whentestingelectricalcomponentsforcontinuitywithamultimeter

(ohmssetting),makesurethatpowertothecircuithasbeen

disconnected.

Groundsmaster

5900&5910

Page6–53

ElectricalSystem:ComponentTesting

16227SLRevB
