ServiceandRepairs
AirFilter
(90 to 100 in-lb)
10 to 11 N·m
1
2
6
3
4
5
6
7
8
9
10
11
12
g287547
Figure15
1.Airlterassembly
5.Airbox9.Intaketube
2.Flangenut(2)6.Flangeheadscrew(2)
10.Hoseclamp
3.Grommet7.Carriagescrew(2)
11.Foamseal
4.Flangenut(2)
8.Hoseclamp12.Foamseal
AirFilterRemoval
1.Parkmachineonalevelsurface,lowercuttingdecks,stopengineand
removekeyfromthekeyswitch.
2.Raisethehoodtoallowaccesstoengine.
3.Removeairltercomponentsasneeded(Figure15).
Note:SeeAirFilterServiceIndicator(page6–108)testinginformation.
4.Inspectintaketube,clampsandfoamsealsforevidenceofwearordamage.
Replacecomponentsasneeded.
Groundsmaster
®
5900&5910
Page4–11
YanmarDieselEngine:ServiceandRepairs
16227SLRevB
