WorkLightandBeaconSwitches(Groundsmaster5910−Optional)
1
2 3
g288543
Figure238
1.Cabheadliner(rightswitchpanel)3.Beaconswitch(optional)
2.Worklightswitch(optional)
Theswitchesarelocatedinthecabheadliner(Figure238).Theswitchesare
usedtoturntheoptionallightkitsonandoff.
Testing
1.Parkmachineonalevelsurface,lowercuttingdecksandstopengine.
Removekeyfromkeyswitch.
2.Toaccesstheswitch,removeroofpanelfromtopofcab(seeRoofAssembly
(page9–9)).
3.Removetheswitchpanelfromcabheadliner.
4.Disconnectmachinewireharnessconnectorfromtheswitchbeingtested.
g288544
Figure239
BackofSwitch
5.TheswitchterminalsaremarkedasshowninFigure239.Thecircuitlogic
ofthethrottleswitchisshowninbelowtable.Withtheuseofamultimeter
(ohmssetting),theswitchfunctionsmaybetestedtodeterminewhether
continuityexistsbetweenthevariousterminalsforeachswitchposition.
Verifycontinuitybetweenswitchterminals.
SWITCHPOSITIONCLOSEDCIRCUITSOPENCIRCUITS
OFF
2+1and5+42+3and5+6
ON
2+3and5+62+1and5+4
6.Replacetheswitchiftestingdeterminesthatitisfaulty.
Groundsmaster
®
5900&5910
Page6–97
ElectricalSystem:ComponentTesting
16227SLRevB
