GeneralInformation
Operator’sManual
TheOperator’sManualprovidesinformationregardingtheoperation,general
maintenanceandmaintenanceintervalsforyourGroundsmastermachine.Refer
totheOperator’sManualforadditionalinformationwhenservicingthemachine.
OperatorCabComponents
InformationregardingGroundsmaster5910cabcomponents(blowers,fans,
pressureswitches,washerpumpandwindshieldwipers)isincludedinChapter
9:OperatorCab(page9–1).
ToroElectronicControllers(TEC)
1
2
3
g288257
Figure135
1.Frontpowercenter(behindoperatorseat)3.Slavecontroller
2.Mastercontroller
Groundsmaster5900and5910machinesusetwo(2)T oroElectronicControllers
(TEC)tomanagemachineelectricalfunctions.TheTECisamicrocontrollerthat
monitorstheconditionofvariousmachineswitchesandsensors(inputs)and
directselectricalpowertocontrolappropriatemachinefunctions(outputs)based
onthestateoftheinputs.CommunicationbetweenthetwoTorocontrollers,
theYanmarenginecontrollerandtheInfoCenterDisplayisprovidedbyaCAN
busnetwork.Thestatusofinputstothecontrollersaswellasoutputsfromthe
controllerscanbemonitoredwiththeInfoCenterDisplay(seeDIAGNOSTICS
SCREENS(page6–22)).
TheTECcontrollersareattachedtothemachineunderthefrontpowercenter
coverbehindtheoperatorseat(Figure135).Thecontrollersareidenticalbut
theyareprogramedina”master/slave”congurationandthereforecannotbe
interchanged.Themastercontrollerisprimarilyresponsibleformanagingthe
enginestartsignalandinterlocks.Theslavecontrollerisprimarilyresponsible
formanagingcuttingunitoperation.
Groundsmaster
®
5900&5910
Page6–3
ElectricalSystem:GeneralInformation
16227SLRevB
