RelayswithFive(5)Terminals

g288565

Figure244

1.Frontpowercenter2.Brakelightrelay

TheGroundsmaster5900and5910useanumberofelectricalrelaysthathave

ve(5)terminals.Atagnearthewireharnessrelayconnectorcanbeused

toidentifyeachrelay.

Thebrakelightrelaysuppliespowertothebrakelights.Thebrakelightrelayis

energizedbythemastercontroller.Thebrakelightrelayislocatedinthefront

powercenterbehindtheoperator’sseat(Figure244).

g288566

Figure245

1.YanmarECU2.EGRrelay

TheEGRrelayisusedtoprovidecurrenttotheengineEGRvalve.TheEGR

relayisenergizedbytheYanmarECU.TheEGRrelayislocatedontheleftside

oftheengineneartheYanmarECU(Figure245).

ElectricalSystem:ComponentTesting

Page6–102

Groundsmaster

5900&5910

16227SLRevB
