Toro Groundsmaster 5910 Series User Manual

Engine
1
2
3
4
4
5
5
6
6
6
g287541
Figure24
1.Coolerframeassembly3.Flangenot(3)5.Flangenut(6)
2.Battery−disconnectswitchbracket
4.Carriagescrew(4)6.Capscrew(6)
EngineRemoval
1.Parkmachineonalevelsurface,lowercuttingdecks,stopengineand
removekeyfromthekeyswitch.
CAUTION
Theengine,exhaustpipe,radiatorandoilcoolermaybehot.To
avoidpossibleburns,allowthemachinetocoolbeforeworkingon
ornearthesecomponents.
2.Turnthebattery−disconnectswitchtotheOFFpositionanddisconnectthe
batterypositive(+)cablesatthebatteriesofthe12Voltand24Voltsystems.
3.Ifengineistobedisassembled,drainoilfromengine.
4.Removehood(seeHoodRemoval(Figure321)(page7–48)).
5.Drainradiatorintoasuitablecontainerusingtheradiatordrain.Theradiator
drainislocatedinsidetherightframerailneartherearwheel.
6.Loosenhoseclampsanddisconnectupperandlowercoolanthosesfrom
theradiator.
7.Loosenhoseclampanddisconnecttheairintakehosefromtheengine.
Groundsmaster
®
5900&5910
Page4–25
YanmarDieselEngine:ServiceandRepairs
16227SLRevB
