EngineRemoval(continued)
8.Topreventcontaminationofhydraulicsystem,thoroughlycleanexteriorofoil
cooler,ttingsandhydraulichosespriortodisconnectinghydraulichoses.
9.Disconnecthydraulichosesfromtheoilcoolerandinstallcapsorplugson
ttingsandhoses.
10.Removethecoolerframeassemblywiththeradiatorandfanassembly,oil
coolerandfanassembly,airlterandplenumassembly,coolantreservoir
andwindshieldwasherreservoirattached(Figure24):
A.Recordthelocationofcableties,clampsandclipsusedtosecurethe
electricalharnesstothecoolerframe.
B.Disconnectthewindshieldwasherreservoirpumpfromthewireharness
(GM5910only).
C.Disconnecttwo(2)oilcoolerfansfromthewireharness.
D.Disconnectairlterserviceindicatorfromthewireharness.
E.Disconnecttwo(2)radiatorfansfromthewireharness.
F.Disconnecttwo(2)radiatorfansfromthewireharness.
G.Supportthecoolerframeassemblefromoverheadandremovethe
fastenerssecuringthecoolerframetothemachine.Liftthecoolerframe
assemblyfromthemachine.
11.Recordthelocationofcableties,clampsandclipsusedtosecurethe
electricalharnesstotheengineandpreparetheengineforremoval:
A.Disconnectthedieselparticulatelter(DPF)fromthewireharness.
B.Disconnectthealternatorfromthewireharnessandthepositive(+)cable.
1 2 3 4 5
6 7 8 9 10
g287542
Figure25
1.Locknut6.Positivebatterycable
2.Fusiblelink7.Wireharness
3.Startersolenoid8.Capscrew
4.Heatshield
9.Flangeheadscrew(2)
5.Flangeheadscrew(3)
10.Heatshield
C.Removetheheatshieldsfromaroundthestartermotoranddisconnect
thepositive(+)batterycable,fusiblelinkandwireharness(Figure25).
YanmarDieselEngine:ServiceandRepairs
Page4–26
Groundsmaster
®
5900&5910
16227SLRevB
