FuseIdentication,LocationandFunction(continued)
•FuseF−C4(30Amp)suppliespowertothehorn.
•FuseF−D4(10Amp)suppliespowertotheUShazardlights.
•FuseF−A5(2Amp)suppliespowertothetelematicsconnector.
•FuseF−B5(2Amp)suppliespowertotheInfoCenterdisplay.
•FuseF−C5isunusedandavailableforoptionalequipment.
•FuseF−D5isunusedandavailableforoptionalequipment.
1
2
FRONT
g288444
Figure200
1.Coolerframe(rightside)2.10ampaccessoryfuse
Raisehoodtoaccessfuseholderattachedtorightsideofcoolerframe
(Groundsmaster5910)(Figure200).
•A10Ampfuseisusedtosupplypowertoanoptionalradio.Thefuseis
un−switched(alwaysenergized)andisintendedtopowertheradiomemory
circuit.
12
g288445
Figure201
1.Cover2.Operatorcabfuseblock
Groundsmaster
®
5900&5910
Page6–59
ElectricalSystem:ComponentTesting
16227SLRevB
